Suitable for hobby, models, science and other projects
| Voltage (Nominal) | 12V |
|---|---|
| Voltage Range (Recommended) | 6V - 18V |
| Speed (No Load)* | 124 rpm |
| Current (No Load)* | 0.10A |
| Current (Stall)* | 3.8A |
| Torque (Stall)* | 419.45 oz-in (30.20 kgf-cm) |
| Gear Ratio | 78:1 |
| Gear Material | Metal |
| Gearbox Style | Straight Cut Spur |
| Motor Type | DC |
| Output Shaft Diameter | 4mm (0.1575”) |
| Output Shaft Style | D-shaft |
| Output Shaft Support | Bushing |
| Electrical Connection | Male Spade Terminal |
| Operating Temperature | -10°C ~ +60°C |
| Mounting Screw Size | 3mm |
| Product Weight | 0.20lb (3.25oz) |
Downloads:
| Specifications (PDF) |  |
| Stock Code | Product Name |
| LS-00086 | 124 RPM DC Metal Gear Motor |
